MOTU AVB Series
One engine, three interfaces, one network — the shared architecture that lets a studio grow a room at a time, without re-buying its core.
Every studio starts with one room and one interface. The moment a second room enters the picture, most setups start compromising — mismatched converters, clocking errors, monitor controllers bought late. The MOTU AVB Series solves this differently: three interfaces, one identical engine, one identical price.
The Shared Engine
Identical in all three chassis — only the front panel changes.
ESS Sabre32 Ultra Conversion
Common to 10pre, 16A & 848
- 64-input, 32-bus CueMix Pro mixer
- 32-bit floating point DSP
- ~1.8ms round-trip latency
- Thunderbolt 4 / USB4, up to 256 channels
Three Interfaces
Same engine, three jobs — choose the front panel your room needs.
10pre
Built to Capture
- 10 mic preamps, up to 74dB gain
- -129dBu equivalent input noise
- 26 inputs, 28 outputs, 54 simultaneous channels
- Inserts on ch. 1 & 2, dual headphone outs, 3.9″ display
16A
Built to Route
- 16 balanced 1/4″ line ins, 16 line outs, all DC-coupled
- 32 inputs, 34 outputs, 66 simultaneous channels
- 2 × 3.9″ displays, ADAT/S-MUX expansion
- Control-voltage-capable outputs
848
Built to Command
- 4 combo preamps, A/B/C speaker switching
- Talkback, mono fold-down, 2 headphone mixes
- 28 inputs, 32 outputs, 60 simultaneous channels
- Removes the need for a separate monitor controller
The Network
Built in for the first two rooms, ready to scale beyond that.
AVB Switch
Milan-Certified Networking
- Built-in 2-port switch ships in every unit
- 6 gigabit ports, up to 100m per run
- Sample-accurate clocking via gPTP
- Scales to 150 devices and 512 streams
Spec Comparison
The full ecosystem, side by side.
| Model | I/O | Simultaneous Channels | Signature Feature |
|---|---|---|---|
| 10pre | 26 in / 28 out | 54 | 10 mic preamps |
| 16A | 32 in / 34 out | 66 | 16 DC-coupled line I/O |
| 848 | 28 in / 32 out | 60 | A/B/C monitor control |
| AVB Switch | 6 gigabit ports | 512 streams | Sample-accurate gPTP clocking |
One Philosophy
Built For
Choose Your Model
Same engine, same price — the fit is about the room, not the conversion.
To specify a system, or arrange a demo, get in touch.
Shivansh Electronics is the Authorized Distributor of MOTU, USA, for East & North East India.
